AEL Single Column Vertical Test Stand

AEL Single Column Vertical Test Stand

The AEL single-column vertical test stand is a push-pull load testing bench specifically designed for use with HF and NK series push-pull force gauges.

It adopts a double-column structure, offering advantages such as good stability, wide applicability, and ease of use. It also features stepless speed regulation and manual (jog) to automatic control switching functions.

It is suitable for push-pull load, insertion/extraction force, and destructive testing in industries such as rubber and plastics, light industry and textiles, building doors and windows, composite materials, wires and cables,

automotive parts, power machinery, and research institutions.

1. Electric loading, stepless speed regulation, gear transmission

2. Compact structure, smooth transmission

3. Simple operation, and can be used with various clamps.

• Maximum load: 500N

• Effective stroke: 200mm, 400mm, 700mm selectable

• Testing speed: 0-280 mm/min

• Operating voltage: 220V

• Dimensions (mm): 280*340*780 (200mm), 280*340*980 (400mm), 280*340*1270 (700mm)

• Net weight: 30kg

Installation Method:

For sensor-embedded push-pull force gauges: Insert 4-M6 screws into the 4-φ6.2 holes of the fixing block, insert one washer in each thread direction, and tighten them onto the 4-M6 threads of the force gauge mounting plate.

The force gauge mounting plate has two sets of mounting holes, 30x145 and 40x90 respectively. Users can determine the appropriate size according to their needs.
